Conductive Gaskets
Conductive Gaskets
EMI Shielding, Environmental Sealing, EMI Gaskets, RF Shielding Gaskets, EMC Gasket
Technical Data:
- Dual Function: EMI Shielding + Environmental Sealing
- Excellent Shielding Effectiveness up to >100 dB
- Stable Performance Across Wide Temperature (-55°C to +160°C)
- Resistance to Chemicals, Oils, and Ozone
- Low Compression Set and Excellent Elastic Recovery
- Complies with RoHS / REACH / UL 94 V-0
- Suitable for Dynamic and Static Applications
- MIL-STD-810, MIL-DTL-83528 Compliant
Product Description
Conductive Gaskets are advanced EMI shielding components made by wrapping conductive fabric or metal foil over a soft foam core. They combine excellent shielding effectiveness with mechanical flexibility and environmental sealing, making them ideal for use in electronic enclosures, seams, and access panels.
These gaskets address key challenges such as EMI leakage, irregular surface contact, and mechanical misalignment. Their compressible core ensures consistent shielding even under low closure force, while also compensating for uneven surfaces and gaps in device assemblies.
Compared to traditional EMI gaskets, our FOF gaskets offer superior elasticity, longer compression life, and custom profile options. Their enhanced conformability and durable construction make them a top choice for reliable and cost-effective EMI management.
Read more in our blog: Choosing the Right EMI Gasket: Fabric-over-Foam vs. Metal Finger Strips
Typical Applications
Conductive Gaskets are widely used in telecom equipment like 5G base stations, switches, and routers, providing effective EMI shielding and environmental sealing for reliable signal performance.
In military and defense systems, conductive gaskets protect communication terminals, radar systems, and electronic control units by preventing EMI leakage and ensuring system stability.
The aerospace industry relies on conductive gaskets for shielding in satellite communication, flight control systems, and avionics modules, maintaining electromagnetic compatibility in critical applications.
Conductive gaskets ensure medical equipment such as MRI systems, ECG monitors, and precision analyzers remain protected from electromagnetic interference and environmental contaminants.
For industrial automation, conductive gaskets provide durable sealing and EMI protection in PLC units, drive controllers, and electrical cabinet assemblies, enhancing operational reliability.
In consumer electronics, conductive gaskets help shield smart devices, laptops, and electronic display frames, ensuring compliance with EMC standards and improving product lifespan.
Shielded environments like chamber doors and enclosures benefit from conductive gaskets to enhance EMI filter integration and maintain strict electromagnetic compatibility.
Product Features
- High Flexibility and Conformability
- Low Compression Set, Long Service Life
- Operates in Wide Temperature Range
- Resistant to Fungus, UV, Ozone, and Chemicals
- Lightweight and Easy to Handle
- Available in Sheets, Gaskets, Die-cut Parts, and Extrusions
- Custom Colors and Profiles Available
- Compatible with Complex Sealing Geometries
Technical Data
| Property | Value / Option |
|---|---|
| Conductive Filler | Silver, Nickel, Graphite, Silver-Aluminum |
| Polymer Base | Silicone, Fluorosilicone, EPDM, NBR |
| Shielding Effectiveness | Up to 120 dB (200 MHz – 10 GHz) |
| Temperature Range | -55°C to +160°C (up to +200°C for some types) |
| Hardness | Shore A 30–80 |
| Compression Set | <10% typical |
| Flammability Rating | UL 94 V-0 (optional) |
| RoHS / REACH | Compliant |
| Available Forms | Sheets, Die-cuts, Extruded profiles, Molded |
Customization Options
- Customizable in color, shape, dimensions, and structure
- Tailor-made shapes and profiles to fit specific applications
- Adhesive backing (conductive or insulating) available
- Integration with metal mesh or fabric for enhanced performance
- Full design support for both prototypes and volume production
Circuit Diagrams
Currently, there is no circuit diagram available for Conductive Gaskets.
If you have any specific requirements or questions, please feel free to contact our customer service or technical support team — we are here to assist you.
Outline Drawing (mm)
| Model | A | B | C | D | E | F | G | H | R |
| ND-1001D | 46.10 | 46.10 | 38.10 | 38.10 | 35.00 | 35.00 | 41.40 | 2.30 | 4.00 |
| ND-1002D | 23.90 | 23.90 | 18.30 | 18.30 | 15.10 | 15.10 | 16.10 | 2.30 | 3.30 |
| ND-1003D | 28.70 | 28.70 | 22.50 | 22.50 | 20.00 | 20.00 | 20.00 | 2.30 | 3.30 |
| ND-1004D | 31.10 | 31.10 | 24.60 | 24.60 | 23.00 | 23.00 | 25.60 | 2.30 | 3.30 |
| ND-1005D | 26.30 | 26.30 | 20.60 | 20.60 | 18.30 | 18.30 | 19.20 | 2.30 | 3.30 |
| ND-1006D | 28.70 | 28.70 | 23.00 | 23.00 | 20.60 | 20.60 | 24.80 | R1 | 3.20 |
| ND-1007D | 36.60 | 36.60 | 29.40 | 29.40 | 27.00 | 27.00 | 32.00 | 2.30 | 3.30 |
| ND-1008D | 28.60 | 28.60 | 23.01 | 23.01 | 20.602 | 20.60 | 39.00 | 1.04 | 3.20 |
| Model | A | B | C | D | E | F |
| ND-1009D | 24.00 | 18.00 | 24.00 | 18.00 | 3.50 | 18.50 |
| ND-1010D | 26.20 | 20.60 | 26.20 | 20.60 | 3.50 | 20.20 |
| ND-1011D | 110.00 | 83.00 | 110.00 | 94.00 | 8.00 | 86.00 |
| ND-1012D | 24.00 | 18.00 | 24.00 | 18.00 | 3.60 | 18.50 |
| ND-1013D | 26.20 | 20.62 | 26.20 | 20.62 | 3.60 | 20.20 |
Note：Customizable in color, shape, dimensions, and structure
Insertion Loss
Insertion loss data for Conductive Gaskets is currently unavailable.
If you have specific performance requirements or would like to learn more, please don’t hesitate to get in touch — we’d be happy to help.
