Input Power Line Filter For Omron Inverter
Input Power Line Filter For Omron Inverter
EMC Filter, Omron Inverter, VFD
Technical Data:
- Rated Voltage: 250/480VAC
- Rated Current: 10-30A
- Rated Frequency: 50/60Hz
- Test Voltage: Line/Line 1450VDC, Line/ Ground 2250VDC
- Climatic Category: 25/085/21
Product Description
This Input Power Line Filter For Omron Inverter effectively suppresses harmonics and surges from the power network, addressing common inverter issues such as over-voltage, over-current, overload, overheating, and malfunction. By stabilizing the input power quality, the filter ensures the reliable and smooth operation of Omron inverters, significantly enhancing their overall performance and extending service life in demanding industrial applications.
A frequent challenge in using Omron inverters is the vulnerability to unstable grid conditions—such as harmonic distortion, voltage transients, and switching noise—which can cause nuisance tripping, thermal stress, or premature failure. The Input Power Line Filter For Omron Inverter directly addresses these issues by cleaning up the input power, reducing electromagnetic interference (EMI), and preventing high-frequency noise from entering the drive, thereby maintaining stable inverter performance in complex electrical environments.
Compared to conventional filters, our Input Power Line Filter For Omron Inverter offers superior insertion loss, compact design, and optimized compatibility with Omron’s drive architecture. This ensures minimal energy loss, simplified installation, and enhanced protection without compromising system efficiency. It’s a trusted solution for OEMs, panel builders, and end users seeking improved EMC compliance and long-term system reliability.
Learn more in our latest blog:
“How Input Filters Enhance the Reliability of Omron Inverters in Industrial Environments”
Typical Applications
The Input Power Line Filter For Omron Inverter is fully compatible with inverters from most brands, providing universal harmonic and surge protection across different drive systems.
In VVVF and servo motor applications, the Input Power Line Filter For Omron Inverter ensures smooth operation by stabilizing input power and preventing signal disturbance.
For dv/dt suppression, the Input Power Line Filter For Omron Inverter minimizes steep voltage changes at the motor terminal, protecting insulation and extending motor life.
In industrial electronic equipment operating with frequency conversion principles, the Input Power Line Filter For Omron Inverter eliminates electrical noise, ensuring reliable system performance in noisy environments.
Product Features
- The filter features a two-stage filtering design, with special materials ensuring high impedance characteristics across a wide frequency range
- Optimized for VVVF and high-noise environments
- Delivers outstanding attenuation for both common mode and differential mode noise, particularly at low frequencies
- The copper bar is suitable for versions above 250A, meeting international standards for simple and secure connections
- CE approved, ensuring compliance with international quality and safety standard
Technical Data
|
Type |
Rated Current (A) |
Rated Voltage | Rated Frequency | I Leakage
(≤mA) |
Test Voltage
(2s) |
Dim | Circuit | Output | Climate Category |
| ND2210-10-W |
10 |
250VAC |
50/60Hz |
Nom/Max 7 |
L—N：1450VDC L—G：2250VDC
|
Fig1 |
Fig1 |
25/85/21 |
|
| ND3210-10-W |
10 |
480VAC |
Nom/Max 3.0/160 |
Fig2 |
Fig2 |
||||
| ND3210-15-W |
20 |
480VAC |
Nom/Max 3.0/160 |
Fig3 |
|||||
| ND3210-30-W | 20 | 480VAC | Nom/Max 1.0/70 |
Fig4 |
Circuit Diagrams
Outline Drawing (mm)
| Type | L | W | H | X | Y | M | Dim |
| ND2210-10-W | 169 | 71 | 45 | 156 | 51 | M4 | Fig1 |
| ND3210-10-W | 169 | 114 | 46 | 156 | 91 | M4 | Fig2 |
| ND3210-15-W | 174 | 144 | 50 | 161 | 120 | M4 | Fig3 |
| ND3210-30-W | 306 | 150 | 52 | 290 | 122 | M5 | Fig4 |
Insertion Loss
Insertion loss data for Input Power Line Filter For Omron Inverter is currently unavailable.
If you have specific performance requirements or would like to learn more, please don’t hesitate to get in touch — we’d be happy to help.
